JKS Manufacturing
JKS Manufacturing J-Max 3.5in Suspension System for 07-18 Jeep Wrangler Unlimited JK 4-Door
(No reviews yet)
Write a Review
- Shipping:
- Calculated at Checkout
$6,333.59
Description
Description
Learn More
Specs
Fitment
As the name suggests, the JKS Manufacturing J-Max 3.5in Suspension System was designed to provide maximum suspension performance to your Jeep Wrangler Unlimited JK. This coilover conversion kit features FOX 2.5 Remote Reservoir DSC Coilovers and bolt-on brackets for premium handling and off-road ability. The included J-Flex control arms are made from 2in x .250-wall DOM tubing, and reduce Noise Vibration and Harshness (NVH) by using factory style rubber bushings. By including all eight adjustable control arms, the J-Max system provides optimal ride quality. To ensure that all suspension and driveline geometry is optimized, JKS also includes front and rear adjustable track bars.
Many states have laws that limit the maximum height of a lifted vehicle. Never exceed the legal height limit.
J-Max System: As the name suggests, the J-Max system is the top of the line lift kit from JKS. By upgrading to bolt-on coilovers, there are no obstacles too tough for your Jeep.
Vehicle Specific Design: This lift kit was engineered for the Wrangler Unlimited JK. The coil springs were specifically tuned for 4-door applications.
Run Larger Wheels and Tires: The JKS Manufacturing J-Max 3.5in Suspension System will allow you to fit 35x12.50 tires on your Jeep.
FOX Racing Shox Coilovers: FOX 2.5 Remote Reservoir DSC Coilovers provide optimum ride and handling. With increased suspension flex, they will improve your Jeep's off-road ability.
Installation Notes
Installation Difficulty:
Level 4Experts Only- Drilling & Cutting Required
- 4.5in or Less Backspacing Required
Installation Time: 14-15 hours
Parts Included
- Front Fox 2.5 Remote Reservoir DSC Coilover Pair
- Rear Fox 2.5 Remote Reservoir DSC Coilover Pair
- Front Coilover Conversion Brackets
- Rear Coilover Conversion Brackets
- Font Adjustable Lower Control Arm Pair
- Rear Adjustable Lower Control Arm Pair
- Front Adjustable Upper Control Arms
- Rear Adjustable Upper Control Arms
- Front Adjustable Track Bar
- Rear Adjustable Track Bar
- Front Sway Bar Disconnects
- Rear Sway Bar End Links
- Front Bump Stop Spacers
- Rear Bump Stop Spacers
- Front Brake Line Drop Brackets
- Installation Hardware
Warranty
Limited Lifetime Warranty - Features: Coil Over, Fixed Lower Control Arms, Front Sway Bar Disconnects, Short Arm
- Shocks Included: With Shocks
- Max Tire Size: 35
- Included Parts: Brake Line Brackets, Bump Stop Extensions, Coil Springs, Front Lower Control Arms, Front Track Bar, Front Upper Control Arms, Hardware, Rear Lower Control Arms, Rear Track Bar Bracket, Rear Upper Shock Mounts, Sway Bar Endlinks
- Shipping Weight: 127
- Shipping Dimensions: 38in x 15in x 19in (L x W x H)
Jeep Wrangler Unlimited 4-Door (JK)
- 2018 Jeep Wrangler Unlimited 4-Door (JK)
- 2017 Jeep Wrangler Unlimited 4-Door (JK)
- 2016 Jeep Wrangler Unlimited 4-Door (JK)
- 2015 Jeep Wrangler Unlimited 4-Door (JK)
- 2014 Jeep Wrangler Unlimited 4-Door (JK)
- 2013 Jeep Wrangler Unlimited 4-Door (JK)
- 2012 Jeep Wrangler Unlimited 4-Door (JK)
- 2011 Jeep Wrangler Unlimited 4-Door (JK)
- 2010 Jeep Wrangler Unlimited 4-Door (JK)
- 2009 Jeep Wrangler Unlimited 4-Door (JK)
- 2008 Jeep Wrangler Unlimited 4-Door (JK)
- 2007 Jeep Wrangler Unlimited 4-Door (JK)
Additional Information
Features: |
Coil Over |
Features: |
Fixed Lower Control Arms |
Features: |
Front Sway Bar Disconnects |
Features: |
Short Arm |
Shocks Included: |
With Shocks |
Max Tire Size: |
35 |
Included Parts: |
Brake Line Brackets |
Included Parts: |
Bump Stop Extensions |
Included Parts: |
Coil Springs |
Included Parts: |
Front Lower Control Arms |
Included Parts: |
Front Track Bar |
Included Parts: |
Front Upper Control Arms |
Included Parts: |
Hardware |
Included Parts: |
Rear Lower Control Arms |
Included Parts: |
Rear Track Bar Bracket |
Included Parts: |
Rear Upper Shock Mounts |
Included Parts: |
Sway Bar Endlinks |
